Amplifier with DSP Steg SS-DSP12 with OTG input for playback directly from a phone via a special high-definition cable and Bluetooth on board.

5999,00 PLN including VAT

Shop only available to approved b2b customers
SKU: Amp000030 Category:

Amplifier with advanced DSP technology with OTG input for playback directly from a phone via a special high-definition cable and Bluetooth on board.

The SS-DSP12 is a true all-rounder amplifier that not only delivers power and dynamics for true hi-fi sound, but at the same time has all the requirements for easy vehicle integration and seamless connectivity. The advanced 32-bit co-processor platform not only takes over all control tasks ultra-fast, but also supports many audio functions: fantastic sound effects such as Augmented Bass Processing or Real Center are implemented.

Technical data:

  • dynamic range: ≤ 100 dB
  • signal-to-noise ratio: ≥ 100 dB
  • Input voltage: High level 32Vpp, RCA 6Vpp
  • Output voltage: High level 28 Vpp, RCA 8Vpp
  • power rating: 12CHx80W(4Ω,14.4V, 1kHz, 10%THD)
  • max power: 12CHX120W(4 Ω,14.4V, 1kHz, 10%THD)
  • power at bridging: 6CHx200W(4 Ω,14.4V, 1kHz, 10%THD)
  • Input/Output sensitivity (RCA): 1:1:3 (without power amplification)
  • frequency: 20Hz~20KHz
  • Input impedance: High level: 10Ω, RCA:47kΩ,
  • output impedance: 51Ω
  • Operating voltage: 9~16V
  • standby power: ≤ 0,1W
  • dimensions: 307mm x 196mm x 50mm
  • weight: 4.2 kg

Weight 4,2 kg
