Categories

2099,00 PLN including VAT

Shop only available to approved b2b customers
Product inquiry
SKU: Amp000048

Audio Control's 5-channel Altitude series amplifier.

FEATURES:

  • High/low level inputs

  • GTO™ (automatic signal detection)

  • Linkwitz-Riley filters

  • Compatible with Start-Stop systems

  • High power output in a compact housing

  • ParaBASS® - low frequency shaping

  • Valet mode

  • Optional remote level control (ACR-1)

  • Compatible with electric vehicles up to 17V

TECHNICAL SPECIFICATIONS

INPUTS

  • Preamp Inputs: 6

  • Line inputs (Line-Level): max. 6 V

  • High-level inputs (Speaker-Level): max. 20 V

OUTPUTS

RMS power (continuous) at 14.4 V:

  • 90W x 4 at 4Ω

  • 125W x 4 at 2Ω

  • 400W x 1 at 4Ω

  • 600W x 1 at 2Ω

Remote level control:

  • ACR-1 (optional)

DIMENSIONS AND WEIGHT

  • Dimensions: 14" (W) x 6.7" (D) x 2.1" (H)

  • Weight: 7.95 lbs (3.6 kg)

PERFORMANCES

  • Signal-to-noise ratio (S/N):

    • 95.1 dBA (channels 1-4)

    • 103.9 dBA (channel 5)

  • THD+N (total distortion): <0.25% (channels 1-4), <0.75% (channel 5)

  • Recommended diameter of supply/ground cables: 4 AWG

  • Recommended protection (fuse): 120A

ADDITIONAL FEATURES

  • Valet Mode: Yes

  • Subsonic filter: Adjustable

  • Linkwitz-Riley crossover (X-Over):

    • Off

    • High Pass

    • Low Pass

    • Frequency range: 50 Hz - 5 kHz

  • Bass processing: ParaBASS®

Weight 2,5 kg
