Ampire CPS090 video recorder in mirror

Multifunctional monitor in the rear-view mirror with integrated smartphone interface.

The device is compatible with wireless Apple CarPlay® and Android Auto (please check minimum requirements), making it a smart and safe way to use your smartphone in the car. In addition, it acts as a driving recorder and also comes with a reversing camera.

Technical data:

Display:

• 9″ IPS LCD touchscreen monitor
• 8.8″ / 22.4 cm visible diagonal
• 36:9 aspect ratio
• Touchscreen operation
• Adjustable LED backlighting
• Very high resolution 1280 x 320
• Brightness 750cd/m²
• Contrast ratio 1000:1
• Refresh rate 60Hz
• Vertical viewing angle 130°
• Horizontal viewing angle 150°
• Our monitors meet ISO 9241-307, class II standard for pixel errors

Smartphone integration:

• Wireless Apple CarPlay Minimum requirements: iPhone 5 and later. The CPS090 can only be connected to Apple CarPlay wirelessly, no USB cable can be used.
• Wireless Android Auto Minimum requirements: Android 11, Android Auto 4.8 and 5GHz WLAN* *IEE standards 802.11a, 802.11ac, 802.11ax, 802.11be and 802.11n NOTE! Devices supporting only 2.4GHz WLAN are not supported and are not compatible! The CPS090 can only be connected to Android Auto wirelessly, a USB cable cannot be used.
• Bluetooth Connect your smartphone to the CPS090, then connect your smartphone to the Bluetooth on the car radio. CarPlay or Android Auto audio is then directly and directly transmitted via Bluetooth A2DP to the car radio* (*Requires a Bluetooth A2DP-enabled car radio).

Front/rear driving recorder:

• Integrated front camera on the back of the monitor
• Analogue high resolution
• 1080p (resolution 1920 x 1080 pixels)
• Frame rate 30 FPS
• Viewing angle: 120° horizontally, 145° diagonally
• Recording resolution: 1080p+1080p or 720p+720p (selectable)
• Segment length: 1 minute, 3 minutes, 5 minutes
• Optional audio recording
• Park mode with motion detection and timelapse recording. 12h or 24h settings, low voltage protection at 11.8V
• Memory card type: microSD (not supplied)
• MicroSD speed class: Class 10 or higher
• Capacity of microSD memory card: min. 32GB to max. 256GB
• Recording capacity: 32GB approximately 4.5 hours, 64GB approximately 9.5 hours, 128GB approximately 19 hours, 256GB approximately 38 hours, after which the oldest recordings are overwritten.
• Switch-on delay (ACC ON): 17 seconds
• Switch-off delay (ACC OFF): 15 seconds

Reversing camera:

• Analogue high resolution
• 1080p (resolution 1920 x 1080 pixels)
• Frame rate 30 FPS
• Viewing angle: 120° horizontally, 145° diagonally
• MINI-DIN 4P system plug
• Dimensions without butterfly handle: 23 x 23 x 32 m
• The system camera for the rear of the vehicle is used as the reversing camera. The installation of an additional reversing camera is not required.
• 12 V input for activation
• Immediate change to full-screen rear camera with auxiliary lines when reverse gear is inserted
• The auxiliary lines can be individually adjusted
• Switch-off delay of 3 seconds after removing reverse gear
• Dashcam recording function is not interrupted in reverse camera mode
• Image playback can be adjusted normal/inverted

Audio output:

• Stereo audio output with 3.5mm jack cable
• Bluetooth A2DP audio transmission of all CarPlay and Android Auto content directly from a smartphone. No additional app required.
• FM transmitter for alternative sound reproduction (87 - 108 MHz.)
• Built-in 2 watt speaker with its own enclosure

Other:

• LINUX 4.9 operating system with 1GB memory
• Apple CarPlay and Android Auto in full-screen mode or in half-screen mode with simultaneous camera display (selectable)
• SD card reader (Micro SD)
• USB-C input for power supply
• USB-C power supply with ACC ignition logic
• Menu languages: DE, EN, CN, RU, ES, FR, IT, PT, JPN and KOR.
• Automatic switching on when supply voltage is applied
• Operating voltage 9V - 36V DC
• Current consumption in ACC ON mode: 590mA@12VDC
• Current consumption in ACC OFF mode: 8mA@12VDC
