Ampire XSA205 fuse holders

A fuse holder with which you can directly draw a separately protected signal from the vehicle's fuse block. Simply remove the original MINI flat fuse and insert the XSA205 instead. Re-insert the original MINI fuse (ATM) into the XSA205 and the desired signal will be protected with the included 5A MINI fuse on a 4 mm diameter round tip.

The kit includes:

• 1 piece fuse holder MINI (ATM) XSA205
• 1 piece MINI (ATM) LITTLEFUSE 5A fuse

Technical data:

• Type of fuse: MINI (ATM) flat fuse
• DIN/ISO: 72581/3C
• Maximum voltage: 32 V
• Maximum current: 5A
• Material: polyamide 6.6
• Conductor cross-section: 1.3 mm²
• Cable length: 120 mm
• Surface: zinc-plated
• SVHC: No SVHC substance!

NOTE

Make sure the fuse holder is inserted in the correct direction. The fuse holder has an input and two outputs.
