The AMPIRE OHV156-HD 15.6″ ceiling monitor

A slim HD monitor with a mounting height of just 30 mm.

The monitor has HDMI and video input. Various video, audio and image formats can also be played via the USB interface. All connections are not on the casing, but are routed out as a cable harness on the bottom of the unit. This enables a professional and durable installation with invisible cabling.

Technical data:

• Operating voltage: 11-14 V DC
• Current consumption: 1,78 A
• Resting current when ignition is switched on: 0,04 A
• Resting current with ignition off: 0,00A
• Operating temperature: -10°C to +70°C
• Closed monitor dimensions: 410x320x30mm
• Dimensions of open monitor: 410x320x260mm
• Monitor opening angle: 180°
• Weight: 2.9 kg
• Connecting cable 2.25 metres long
• EQUIPMENT
  - Integrated lighting via 8 LEDs (can be switched off)
  - Integrated blue ambient lighting (can be switched off)
  - Control buttons with blue night-lighting
  - Infrared remote control
• VIDEO
  - Inputs: HDMI, AV (cinch), USB (all connectors on the rear of the unit on the wiring harness)
  - AV video output via cinch, but only when AV video input is selected (not for HDMI and USB)
• AUDIO
  - Stereo audio output via Cinch connector. We recommend connecting this output to the AUDIO AUX socket of the car radio.
  - Infrared transmitter for optional wireless headphones (item number: HP301) with two adjustable infrared channels: A (2.8 MHz + 2.3 MHz) or B (3.8 MHz + 3.2 MHz).
  - The integrated FM transmitter allows the audio to be played as an FM radio station via the car radio. The following FM frequencies can be set: 87.7, 87.9, 88.0, 88.1, 88.2, 88.3, 88.4, 88.5 and 88.6 MHz. We recommend using the FM transmitter for audio transmission only in emergency situations. This is because the limited FM audio quality is not high.
• USB INPUT
  - Video: MPEG1/2/4, RM, RMVB, MOV, D AND V X, MJPEG
  - Audio: WMA, MP3, M4A, AAC
  - Images: BMP, JPEG, GIF, PNG, TIFF
  - USB 2.0 memory stick support
• LCD DISPLAY
  - Screen diagonal: 39.6 cm (15.6″)
  - AUO high-resolution digital LCD panel
  - LED backlighting
  - Resolution: 1920 x 3 (RGB) x 1080 pixels
  - Brightness: >300 nits
  - Contrast ratio: >500:1
  - Horizontal viewing angle: 140°
  - Vertical viewing angle: 120
  - 262,144 / 16,777,216 colours (18-bit / 24-bit)
  - Video standard: PAL/NTSC
  - Switching between 16:9 and 4:3 aspect ratios
  - Our monitors are subject to ISO 9241-307, pixel error class II.

Certificates:
- CE Approval, Report No. BST16087768A0001Y-1ER-1
- REACH authorisation, report no. BST16087768A0001Y-1RR4
- E11 10R 023588
