Ampire KCA202 reversing camera

KCA202 Mini Mounting Camera with Wide Angle Lens is a reversing camera with an unlimited range of applications - in cars, buses, campervans, trucks or trailers.
The matte black plastic housing is extremely weatherproof, waterproof to IP69K and very solidly constructed. The handle is made of powder-coated stainless steel, together with stainless steel screws.
A 10-metre extension cable with high-quality copper wire is included.

FEATURES

• Wide angle AHD camera in plastic housing

• Adapted for continuous operation 24/7

• IP69K waterproof with stainless steel handle

• Infrared illumination for night vision

THE KIT CONTAINS

• Mounting camera with bracket

• 10 m extension cable AK1039

• AK1037 power supply

• Operating manual

TECHNICAL DATA

• Image sensor type: AHD 1/4″ 2729

• Video signal: 1080P, 25 frames/second

• Resolution: 1920×1080 pixels

• Auxiliary lines: factory switched on (can be switched off)

• Housing: matt black plastic, stainless steel attachment

• Image playback: mirrored (adjustable)

• Protection class: IP69K

• Exposure: 1/50-60 ~ 1/15000 seconds

• Signal-to-noise ratio: ≥60.5 dB

• Dynamics: >>74 dB

• Light sensitivity: 0 Lux under IR illumination

• Output signal: 1.0Vp-p, 75 Ohm (AHD)

• Automatic white balance

• Automatic video level adjustment

• Supply voltage: 6-26 V DC

• Current consumption: 200-230 mA @ 12 V

• Viewing angle: diagonal 160°, horizontal 137°, vertical 77°

• Camera dimensions: 60×40×40 mm

• Dimensions of camera with handle: 72×55×45 mm

• Operating temperature: -40°C to +75°C

• Storage temperature: -60°C to +105°C

• Certification: E

CERTIFICATES

• CE Directive 2004/108/EC, EN55022:2010, EN55024:2010, Report No. STR12058091E

• FCC Part 15B, Report No. STR12058092E-3

ADDITIONAL KEYWORDS

KC201, kc201, KC202, kc202

ORDER INFORMATION

This camera is a high-resolution AHD camera with 1080P resolution and 25 fps. It can only be connected to compatible monitors, car radios or interfaces.
If the camera input on your monitor only supports CVBS, FBAS or NTSC signals, this AHD camera will not be suitable - in this case, use a CVBS version with an NTSC signal, technically identical in design.
