Signal generator AMPIRE 55000

Does your factory car radio not have a remote control output for switching on amplifiers or an active subwoofer?
The AMPIRE 55000 remote control signal generator generates a 12 V power line with a delay of approximately 1 second with almost any input signal (including loudspeaker signals). The 55000 can also be used to create a telephone mute.

The 55000 works only with the BTL input signal. Both speaker outputs are connected to the amplifier, one being driven by the inverted signal of the other. This technique is often used in car amplifiers as it allows more power to be produced with the 12 V available.

Technical data:

• Operating voltage: 12 Volt DC
• Output voltage: 12 Volt DC
• Maximum output current: 1 Ampere
• Switch-on delay: 0.8 to 1.5 seconds
• Maximum resting current: 0.0016A
• Maximum operating current: 0.027A (on)
